Product Summary
The 2N7002 is a N-channel enhancement mode vertical D-MOS transistor in a SOT23 envelope. It is designed for use as a Surface Mounted Device (SMD) in thin and thick-film circuits, with applications in relay, high-speed and line transformer drivers.
Parametrics
2N7002 absolute maximum ratings: (1)drain-source voltage: 60 V; (2)gate-source voltage: 40 V; (3)drain current: 180 mA; (4)drain current: 800 mA; (5)total power dissipation: 300 mW; (6)storage temperature range: -65 to 150 ℃; (7)junction temperature: 150 ℃.
Features
2N7002 features: (1)Direct interface to C-MOS, TTL, etc; (2)High-speed switching; (3)No secondary breakdown.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 2N7002\E9 |
Vishay Semiconductors |
MOSFET SOT-23 N-CH 60V 0.25 |
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002_D87Z |
Fairchild Semiconductor |
MOSFET N-Ch Enhancement Mode Field Effect |
Data Sheet |
|
|
||||||||||||
 |
2N7002_L99Z |
Fairchild Semiconductor |
MOSFET NCh Enhancement Mode |
Data Sheet |
Negotiable |
|
||||||||||||
|
2N7002_Q |
Fairchild Semiconductor |
MOSFET N-CHANNEL 60V 115mA |
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002-7 |
Diodes Inc. |
MOSFET 60V 200mW |
Data Sheet |
Negotiable |
|
||||||||||||
|
2N7002A |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002E,215 |
NXP Semiconductors |
MOSFET TAPE7 MOSFET |
Data Sheet |
|
|
||||||||||||
 |
2N7002CK,215 |
NXP Semiconductors |
MOSFET Trans MOSFET N-CH 60V 0.3A 3-Pin |
Data Sheet |
|
|
||||||||||||
