Product Summary
The GDS1110BD is a general-purpose, 32-bit RISC microprocessor with a 16 Kbyte instruction cache (Icache), an 8 Kbyte write-back data cache (Dcache), a minicache, a write buffer, a read buffer, an MMU, an LCD controller, and serial I/O combined in a single component. The GDS1110BD provides portable applications with high-end computing performance without requiring users to sacrifice available battery time. Its power-management functionality provides further power savings. For embedded applications, the GDS1110BD offers high-performance computing at consumer electronics pricing with MIPS-per-dollar and MIPS-per-watt advantages. The GDS1110BD delivers in price/performance and power/performance, making it a chice for portable and embedded applications. The GDS1110BD differs from the Intel StrongARM SA-1100 Microprocessor (SA-1100) only in the features of its memory and PCMCIA controller.
Parametrics
GDS1110BD characteristics: (1)Minimum internal power supply voltage: 1.47 V; (2)Nominal internal power supply voltage: 1.55 V; (3)Maximum internal power supply voltage: 1.63 V; (4)Minimum external power supply voltage: 3.00 V; (5)Nominal external power supply voltage: 3.30 V; (6)Maximum external power supply voltage: 3.60 V; (7)Typical power dissipation: Normal mode = <240 mW, Idle mode = <75 mW, Sleep mode = <50 μA; (8)Ambient operating temperature 0℃ min, 70℃ max.; (9)Storage temperature -20℃ to +125℃.
Features
GDS1110BD features: (1)High performance: 150 Dhrystone 2.1 MIPS @ 133 MHz, 235 Dhrystone 2.1 MIPS @ 206 MHz; (2)Integrated clock generation: Internal phase-locked loop (PLL), 3.686-MHz oscillator, 32.768-kHz oscillator; (3)Power-management features: Normal (full-on) mode, Idle (power-down) mode, Sleep (power-down) mode; (4)Big and little endian operating modes: 3.3-V I/O interface.
Diagrams
 |
